Air Pressure Detoxification Machine – Official Clinical Overview & Technical Datasheet

PRODUCT IDENTIFICATION

Device Name: Air Pressure Detoxification Machine (Sequential Pneumatic Compression System)
Model Series: APD-9000 Series (Pro, Elite, Mobile)
OEM Manufacturer: [Placeholder for OEM Name] – Class II Medical Device Manufacturer
Role: Non-invasive, closed-loop pneumatic pressure therapy system for interstitial fluid mobilization and lymphatic drainage.

CLINICAL ARCHITECTURE & DESIGN

The Air Pressure Detoxification Machine operates on the physiological principle of Sequential Gradient Pneumatic Compression. The system generates a controlled, multi-chamber air pressure waveform that propagates directionally (distal-to-proximal) across eight independent overlapping cells within the medical-grade extremity garment.

Key engineering subsystems:
– Electro-pneumatic pressure regulation module (accuracy ±2 mmHg)
– Eight-zone sequential air cell array
– Rapid exhaust valve system (≤200ms decompression)
– DSP-controlled pressure ramp profiles
– Emergency pneumatic bleed-off safety circuit

INDICATIONS FOR USE (Cleared Applications)

– Adjunctive treatment for venous and lymphatic return
– Reduction of temporary lower extremity edema
– Pre- and post-surgical decongestion protocols
– Management of mild-to-moderate lipedema symptoms
– Post-exercise metabolic waste clearance acceleration
– Contraindications: DVT, severe arteriopathy, acute infection, pregnancy, malignancy

TREATMENT PROTOCOL STANDARDS

Session duration: 25-45 minutes
Pressure range: 30-120 mmHg (adjustable in 1 mmHg increments)
Hold time: 0-10 seconds per chamber
Cycle delay: 0-6 seconds
Treatment modes: Sequential, Wave, Massage, Gradient Boost
Garment types: Full leg, hip & abdomen, arm, multi-limb

Parameter	Specification
Maximum Air Pressure	120 mmHg ±2 mmHg
Number of Pressure Chambers	8 overlapping cells per garment
Cycle Time per Chamber	0–99 seconds (programmable)
Pressure Rise Time (0 to 120 mmHg)	≤ 4.5 seconds
Exhaust Time (120 to 5 mmHg)	≤ 1.2 seconds
Operating Pressure Accuracy	±2 mmHg from setpoint
Dimensions (Control Unit)	280 mm W x 220 mm D x 140 mm H
Weight (Base Unit)	3.8 kg
Electrical Input	100–240V AC, 50/60Hz, 1.8A
Patient Garment Material	Medical-grade TPU laminated nylon, latex-free

COMPLIANCE & SAFETY CERTIFICATIONS

– IEC 60601-1 (Medical electrical equipment – General requirements)
– IEC 60601-1-2 (Electromagnetic compatibility)
– ISO 13485:2016 (Quality management systems – Medical devices)
– FDA 510(k) clearance (Class II – Product Code: BYO)
– CE MDR (Regulation EU 2017/745)
– RoHS 3 (Directive 2015/863/EU)
– Reach compliant

Built-in redundancies: Dual overpressure sensors, automatic shutoff at 130 mmHg, 24-hour self-diagnostics, power-loss rapid deflation valve.

CLINICAL WORKFLOW INTEGRATION

Pre-treatment assessment: Contraindication screening + baseline limb circumference measurement
User interface: 7-inch capacitive touch display, patient protocol presets, real-time pressure curve visualization
Data export: USB port for session logs (CSV format) | HL7 ready for EMR integration (optional module)
Cleaning protocol: Intermittent duty cycle, surface disinfectant compatibility (quaternary ammonium compounds)

OPERATIONAL & WARRANTY SPECIFICATIONS

Duty cycle: 24/7 continuous operation (active cooling fan)
Acoustic noise: ≤55 dB(A) at 1m
Power consumption: 180W maximum
Warranty: 24 months hardware | 12 months pneumatic hose assembly | Lifetime software updates
Included accessories: 1 pair standard leg garments (S/M/L/XL), 4m pneumatic hose, field-replaceable inline bacterial filter (0.2μm), hanging hooks
Service interval: Annual pneumatic calibration check (audible + digital log)
